19 U-CONTROL UMA25S User Manual
Assigning the superior GLOBAL SEND CHANNEL:
1. Press the EDIT/EXIT push button for a short time. The device switches to
EditMode. “Edt” appears on the display.
2. Now press the GLOBAL key (to be found in the CH ASSIGN section).
“GLo”appears on the display for a short time.
3. Use the keyboard to enter two digits for the GLOBAL SEND CHANNEL you
want to use (for example, “0” and “6” for MIDI channel 06).
4a. Press the ENTER key to conrm. The EDIT LED goes out.
4b. Alternatively, press the EDIT/EXIT push button to cancel any changes you
made and to exit Edit Mode The EDIT LED goes out.
◊ To select the channel in CH ASSIGN Mode, it is possible to use the
+/- push buttons below the display instead of the keyboard with its
labeled numbers.
◊ Please note that the channel assignment in GLOBAL EDIT Mode differs
from the above described GLOBAL SEND CHANNEL method! For more
infor mation, read Chapter 5.7.
5.6.4 Snapshot send (Send TX)
The Snapshot Send transmits all values of the current controller positions.
This allows a synchronization of the UMA25S’ settings with the connected
MIDIdevice.
1. Press the EDIT push button.
2. Press the SNAP TX key. The UMA25S transmits the status of all control
elements including the positions of the 8 rotary knobs, the state of the
8push buttons, etc.
After sending the snapshot the UMA25S switches to Play Mode.
◊ In addition to the Snap TX function, there is also the Single Preset
Dump (see Chapter 5.7). Both of these functions differ in the type of
data they send. With a Snapshot Send, only the current control values
are transmitted, which are synchronized with the connected MIDI
device. A Single Preset Dump on the other hand allows the entire
content of the current preset, including the present control element
assignment, to be transmitted. This function allows you easily to
archive and exchange individual presets with other U-CONTROL users.
5.6.5 Sending a notes o message
It may happen that a Note O message cannot be transmitted when the
connection between the UMA25S and the other devices is interrupted in which
case the notes keep on playing. This kind of situation requires you manually to
trigger the Notes O message which mutes all connected sound modules at once.
The Notes O message is sent to each of the 16 MIDI channels.
1. Press the EDIT push button.
2. Press the NOTES OFF key. The Notes O message is immediately transmitted.
“NOF” appears on the display.
The device automatically switches to Play Mode.
5.6.6 Action send function
The Action Send function lets you trigger the transmission of a specic control
element. For example, this function allows you to send a one-o MIDI message
which is only supposed to be assigned to a control element for a short time.
1. Press and hold down the EDIT push button.
2. Turn the control element that you want reassigned.
3. Release the EDIT push button.
4. Use E9 to E16 to make the assignment.
5. Press the ACTION SEND key. The MIDI message is trans mitted.
6a. Press the EDIT/EXIT push button to discard any changes you made.
6b. Alternatively, if you want to keep the new assignment, press ENTER to
conrm. Additionally, store the changes in a preset.
5.7 Settings in global mode
In Global Mode, you can make all settings that aect the device as a whole,
except for the presets.
1. Press and hold down the EDIT/EXIT push button while you press the MUTE
push button (4).
2. You are now in Global Mode and can release both push buttons. “GLb” for
Global Mode appears on the display.
3. Now you can make the necessary settings by using the rotary knobs E9 to
E16. The assignment of the knobs is as follows:
E9 E10 E11 E12 E13 E14 E15 E16
Global
Receive
Ch.
Device ID Dump All
Dump
Single
MMC
Frame
Rate
Select
Factory
Reset
—
Global
Send
Channel
1-16, O 1-16 Run/End Run/End
O, 24,
25, 30d,
30
FAC — 1-16
Table 5.2: Rotary knob assignment in Global Mode
4. Press the EDIT/EXIT push button to exit Global Mode.
◊ The settings in Global Mode are directly taken over and need not be
separately stored.
Global Receive Channel:
The UMA25S receives Program Change messages on this channel in order to load
the presets.
◊ Please note that the channel assignment in CH ASSIGN Mode
differs from the described method in GLOBAL EDIT Mode! For more
information, read Chapter 5.6.3.
Device ID Number:
Only change the Device ID number settings when you are working with several
U-CONTROLs at the same time and encounter problems recognizing the correct
device during a SysEx dump.
◊ Please note that SysEx dumps can only be received at the Device ID
number from which they were sent!
