Operation Verification 110
Table B-5. Operation Verification Test Parameters for Series 665xA (continued)
Test Description Minimum Spec Results * Maximum
Spec
Measurement
Uncertainty
MODEL Agilent 6655A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-51 mV ____________ mV + 51 mV
2.0 µV
Front Panel Display Readback Vout -80 mV ____________ mV Vout +80 mV
2.0 µV
High Voltage (120 V) V
out
119.877 V _____________V 120.123 V 1.7 mV
Front Panel Display Readback Vout -164 mV ____________ mV Vout +164 mV 1.7 mV
Current Programming and Readback
Low Current (0 A) I
out
-4 mA ____________ mA +4 mA
15 µA
Front Panel Display Readback Iout -3 mA ____________ mA Iout +3 mA
15 µA
High Current (4 A) I
out
3.990A ____________ A +4.010 A
586 µA
Front Panel Display Readback Iout -9 mA ____________ mA Iout +9 mA
586 µA
* Enter your test results in this column.
