Exploded View
Parts List
The PH-88 headset is a super lightweight, single sided headset for the ultimate in
day-long comfort. The PH-88 features a high quality monaural dynamic earphone
with dynamic noise cancelling microphone on an adjustable boom that can be bent
to practically any mouth-to-mic position. The unit has a straight cord and is avail-
able in various connector configurations.
Parts List and Wiring Diagrams
Model PH-88 Headset
METI
.ON
NOITPIRCSEDYTQ.ONTRAP
1neercsdniW1100-74795
2,wercSdaeHnaP-TP
kcalB,.GL)632.(6x51AK
2063-404095
3gnirpSredilG2000-50346
4.yssAgnisuoH1701-80346
5.yssAredilG2000-01346
6.yssApmAdroC1350-11346
7.yssAgnisuoH/ciMmooB1000-994008
8.yssAdnabdaeH1620-25346
9etalPelpmeT1200-13507
01daPmaoF1000-33507
11noihsuCraE1000-626095
21,E88-HP&88-HP,rotcennoC
F4-RLX
1400-02353
M4-RLX,R88-HP,rotcennoC1400-89353
M5-RLX,5R88-HP,rotcennoC1500-89353
Specifications
Receiver Type .............................................................................. Dynamic
Receiver Impedance ................................................................... 300 ohms
Microphone Type......................................................................... Dynamic
Microphone Impedance .............................................................. 200 ohms
Weight ............................................................................................. 4.6 ozs
Cord ....................................................................................... 6 ft. straight
